WEIDA Machine
Discover the VNM1100 Vertical Machining Center: Precision engineering, advanced features, and enhanced productivity for all your machining needs. Explore now!
Key Features
- Product Name Vertical machining center
- Service 24 hours after-sales services, Customized services, OEM services
- The VNM1100 Vertical Machining Center adopts a vertical frame design , with the column firmly mounted on the bed . The spindle head moves vertically along the column (Z-axis) , the saddle travels longitudinally along the bed (Y-axis) , and the worktable moves transversely along the saddle (X-axis) .
- - Cross slide structure, inverted Y-column
- - Super rigidity of bed, column, slide, table and spindle box.
- - X,Y and Z guideways are roller linear guideways.
Technical Specifications
| Main specifications | Unit |
| Table size | mm |
| T-slot (Width-Qty-Distance) | mm |
| Max. table load | kg |
| X-axis travel | mm |
| Y-axis travel | mm |
| Z-axis travel | mm |
| Distance from spindle nose to table surface | mm |
| Distance from spindle axis to column surface | mm |
| Spindle taper | -- |
