WEIDA Machine
The machine equiped with hollow hydraulic chuck and hydraulic tailstock,which improves the clamping efficiency and lay the foundation for the automatic processing of the machine.
Key Features
- The machine equiped with hollow hydraulic chuck and hydraulic tailstock,which improves the clamping efficiency and lay the foundation for the automatic processing of the machine.
- Service 24 hours after-sales services, Customized services, OEM services
- - Germany precision lead screw bearings
- - Optional power turret as Y ax i s
- φ700( disk parts )/φ600(shaft parts)
- 12 positions hydraulic or servo turret, box way, Y axis power turret(optional)
Technical Specifications
| Max.swing diameter over bed | mm |
| Max.processing diameter | mm |
| Max.swing diameter over carriage | mm |
| Max. processing length | mm |
| Spindle motor power | 22kw |
| Spindle bore | mm |
| X/Z axis lead screw size | 4010-C3/4010-C3 |
| X axis travel | mm |
| Z axis travel | mm |
| Chuck size(hydraulic) | 15” |
| Center height of turret | mm |
| Tailstock sleeve diameter | mm |
